Notes:
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0162 19P FFC [M]
2 REEV0163 19P FFC (DECK-MAIN) [M]
3 REEV0164 22P FFC(CD-MAIN) [M]
4 REEV0165 22P VFFC (USB) [M]
5 REXX0230-2 2P WIRE (MAIN TO CR120) [M]
6 RGBV0016-S PANASONIC BADGE [M]
7 RGKV0159-K PHONE ORNAMENT [M]
8 RGKV0160-K USB ORNAMENT [M]
9 RGKV0161-S VOLUME RING [M]
10 RGLV0071-Q POWER LIGHTING TIP [M]
11 RGUV0168-K FUNCTION BUTTON [M]
12 RGUV0169-S POWER/REC BUTTON [M]
13 RGUV0170-S CD EJECT BUTTON [M]
14 RGUV0171-S STOP/AUX BUTTON [M]
15 RGUV0172-K CASS EJECT BUTTON [M]
16 RGWV0047-S VOLUME KNOB [M]
17 RHD26046-L SCREW [M]
18 RHD30007-K2J SCREW [M]
19 RHDV30005 SCREW [M]
20 RHGV0008 LEG CUSHION [M]
21 RKF0688A-KJ CASS HOLDER [M]
22 RKFV0064-S CD LID [M]
23 RKMV0072-K1 FRONT PANEL [M]
24 RKMV0073-K SIDE PANEL LEFT [M]
25 RKMV0074-K SIDE PANEL RIGHT [M]
26 RKMV0075-K TOP CABINET [M]
27 RKSV0037-K REAR CABINET [M]
28 RKWV0069-R FL WINDOW [M]
29 RMB0448-J LOCK ROD SPRING [M]
30 RMB0780-1 CASS OPEN SPRING [M]
31 RMBV0043 EARTH SPRING [M]
32 RMKV0063 BOTTOM CHASSIS [M]
33 RMM0163-1 CASSETTE LOCK ROD [M]
Ref.
No.
Part No. Part Name & Description Remarks
34 RMNV0062 FL HOLDER [M]
35 RSCV0086 USB BOTTOM CASE [M]
36 RSCV0087B USB TOP CASE [M]
37 RSCV0088 REAR SHIELD PLATE [M]
38 RUS757ZAA CASS HALF SPRING [M]
39 RXGX0002 DAMPER GEAR [M]
40 RXXV0050 HEAT SINK UNIT [M]
41 SHE187-4J POWER PCB SUPPORT [M]
42 XTB3+10JFJK SCREW [M]
43 XTB3+20JFJK SCREW [M]
44 XTB3+8FFJ SCREW [M]
45 XTB3+8JFJ SCREW [M]
46 XTV3+10GFJ-M SCREW [M]
CASSETTE DECK
101 RED0067-2 P/B HEAD [M]
103 RDG0300 REEL BASE GEAR [M]
104 RDG0301 WINDING RELAY GEAR [M]
105 RDK0026-4 MAIN GEAR [M]
107 RDV0033-4 WINDING BELT [M]
108 RDV0064-1 CAPSTAN BELT [M]
110 RMB0312 TRIGGER LEVER SPRING [M]
111 RMB0400 REEL SPRING [M]
112 RMB0403 HEAB PANEL SPRING [M]
113 RMB0404 BRAKE ROD SPRING [M]
114 RMB0406-5 FR LEVER SPRING [M]
115 RMB0408 THRUST SPRING [M]
116 RML0370-4 TRIGGER LEVER [M]
117 RML0371 FR LEVER [M]
118 RML0372-2 WINDING LEVER [M]
119 RML0374-2 EJECT LEVER [M]
120 RMM0131-1 BRAKE ROD [M]
121 RMM0133-1 EJECT ROD [M]
122 RMQ0519 REEL HUB [M]
22 Replacement Parts List
·
Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthe rmore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specifi ed parts shown in the parts list.
·
The parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
·
Warning: This product uses a laser diode. Refer to “Precaution of Laser Diode”.
ACTUNG:
Die Lasereinheit nicht zerlegen.
Die Lasereinheit darf nur gegen eine vom Hertsteller spezifizierte Einheit ausgetauscht werden.
·
Capacitor values are in microfarads (µF) unless specified otherw ise, P= Pico-farads (pF), F= Farads.
·
Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
·
T he marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
·
[M] Indicates in the Remarks columns indicat es parts supplied by PAVCSG.
·
Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp: Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian Ur: Ukraine
