Ref.
No.
Part No. Part Name & Description Remarks
123 RMS0398-1 MOVING CORE [M]
124 RXQ0470-2 PLUNGER ASSY [M]
125 RMC0061 PACK SPRING [M]
126 RXF0061-1 FLYWHEEL F ASSY [M]
128 RXG0040 FF RELAY GEAR ASSY [M]
129 RMK0283A-2 SUB-CHASSIS [M]
130 RXL0124 PINCH ROLLER F ASSY [M]
130-1 RMB0401 PINCH ARM SPRING F [M]
132 RXL0126 WINDING ARM ASSY [M]
133 RXQ0412-3 HEAD PANEL ASSY [M]
133-1 RMB0405-1 FR ROD SPRING [M]
133-2 RMM0132-1 FR ROD [M]
134 REM0120 CAP MOTOR ASSY [M]
135 RHD26022-1 MOTOR SCREW [M]
136 XTW2+5LFJ HEAD BLOCK UNIT SCRE [M]
137 XTW26+10SFJ SUB-CHASSIS SCREW [M]
138 XYC2+JF17FJ PCB EARTH SCREW [M]
139 RFKJSTR280PP CHASSIS ASS’Y [M]
TRAVERSE DECK
301 RAE0165Z-V TRV UNIT (W/O SERVO P.C.B) [M]
302 RDG0460A CAM GEAR [M]
303 RDG0461A DRIVE GEAR [M]
304 RGQ0254-K2 TRAY [M]
305 RHD30083-1 CAM. GEAR SCREW [M]
306 RHM0001 MAGNET [M]
307 RMB0603-1 FLOATING SPRING [M]
308 RFKNANS55P-K CLAMPER HOLDER ASS’Y [M]
309 RME0288-1 CENTERING SPRING [M]
310 RMG0510-K FLOATING RUBBER (A) [M]
311 RMG0511-K FLOATING RUBBER (B) [M]
312 RMK0422A MECHA CHASSIS [M]
313 RMR1223-K1 CLAMP PLATE [M]
314 RMR1242-X3 FIXTURE [M]
315 XTN2+6GFJ SCREW [M]
316 K0F111E00093 OPEN SWITCH [M]
PRINTED CIRCUIT BOARD
REPV0092B DECK P.C.B / TAPE EJECT
P.C.B
[M]
(RTL)
REPV0119A MAIN P.C.B / PANEL P.C.B /
HEADPHONE P.C.B / MUSIC PORT
P.C.B / TRANSFORMER P.C.B
[M]
(RTL)
REPV0101A USB P.C.B. [M]
(RTL)
REPX0321F DECK MECHANISM P.C.B [M]
(RTL)
REPV0111A CD SERVO P.C.B [M]
(RTL)
INTEGRATED CIRCUITS
IC101 C0DAZYY00006 IC CD 7.5V REGULATOR [M]
IC102 C0DAZYY00005 IC USB 5V REGULATOR [M]
IC300 AN17831A IC POWER AMPLIFIER [M]
IC301 C1AB00002751 IC RDS [M]
IC700 C0ABBB000297 IC OP-AMP [M]
IC800 C1BB00000732 IC ASP [M]
IC801 C0CAABC00007 IC RESET [M]
IC802 C0EBE0000455 IC RESET [M]
IC803 MN101EF16ZXW IC MICROPROCESSOR [M]
IC900 C0HBB0000057 IC FL DRIVER [M]
IC900 MNZSFB5KJM1 IC USB CONTROLLER [M]
IC951 C0DBZYE00002 IC VOLTAGE REGULATOR [M]
IC971 CNB13030R2AU PHOTO INTERRUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SWITCH [M]
IC1001 AN7326K IC P/B REC AMP [M]
IC7001 MN6627954MA IC SERVO PROCESSOR/DIGITAL
SIGNAL PROCESSOR/DIGITAL
FILTER D/A CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Ref.
No.
Part No. Part Name & Description Remarks
Q221 B1ABGC000001 TRANSISTOR [M]
Q222 B1ABGC000001 TRANSISTOR [M]
Q421 B1ABGC000001 TRANSISTOR [M]
Q422 B1ABGC000001 TRANSISTOR [M]
Q600 B1AACF000063 TRANSISTOR [M]
Q601 2SC3940ARA TRANSISTOR [M]
Q602 B1GACFJJ0018 TRANSISTOR [M]
Q603 2SB0621AHA TRANSISTOR [M]
Q750 B1GDCFGG0026 TRANSISTOR [M]
Q751 B1GBCFJJ0044 TRANSISTOR [M]
Q803 B1GBCFJJ0044 TRANSISTOR [M]
Q807 B1GBCFGJ0016 TRANSISTOR [M]
Q808 B1GBCFGJ0016 TRANSISTOR [M]
Q1101 B1ABGC000005 TRANSISTOR [M]
Q1201 B1ABGC000005 TRANSISTOR [M]
Q1302 B1GDCFJJ0002 TRANSISTOR [M]
Q1303 B1GBCFGH0001 TRANSISTOR [M]
Q1304 B1GDCFGH0002 TRANSISTOR [M]
Q1309 B1AAGC000006 TRANSISTOR [M]
Q1310 B1AAGC000006 TRANSISTOR [M]
Q1312 B1ABCF000011 TRANSISTOR [M]
Q1314 B1GDCFGH0002 TRANSISTOR [M]
Q1315 B1ACKD000006 TRANSISTOR [M]
Q1316 2SD09650RA TRANSISTOR [M]
Q1317 B1ABGC000005 TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
DIODES
D500 B0EAKM000117 DIODE [M]
D502 B0EAKM000117 DIODE [M]
D503 B0EAKM000117 DIODE [M]
D504 B0EAKM000117 DIODE [M]
D505 B0EAKM000117 DIODE [M]
D506 B0EAKM000117 DIODE [M]
D507 B0EAKM000117 DIODE [M]
D508 B0EAKM000117 DIODE [M]
D600 B0ACEL000004 DIODE [M]
D602 B0EAKM000117 DIODE [M]
D603 B0EAKM000117 DIODE [M]
D604 B0EAKM000117 DIODE [M]
D605 B0EAKM000117 DIODE [M]
D606 B0EAKM000117 DIODE [M]
D607 B0BC6R700006 DIODE [M]
D608 B0ACEL000004 DIODE [M]
D609 B0EAKM000117 DIODE [M]
D610 B0BC02900004 DIODE [M]
D611 B0EAKM000117 DIODE [M]
D612 B0EAKM000168 DIODE [M]
D613 B0EAKM000168 DIODE [M]
D614 B0EAKM000168 DIODE [M]
D615 B0EAKM000168 DIODE [M]
D616 B0EAMM000038 DIODE [M]
D617 B0EAMM000038 DIODE [M]
D618 B0EAMM000038 DIODE [M]
D619 B0EAMM000038 DIODE [M]
D625 B0EAKM000168 DIODE [M]
D626 B0EAKM000168 DIODE [M]
D627 B0EAKM000168 DIODE [M]
D750 B0ACEL000004 DIODE [M]
D751 B0ACEL000004 DIODE [M]
D800 B0ACCE000003 DIODE [M]
D801 B0ACCE000003 DIODE [M]
D802 B0ACEL000004 DIODE [M]
D804 B0ACEL000004 DIODE [M]
D805 B0ACEL000004 DIODE [M]
D900 B0BC5R600003 DIODE [M]
D906 B3AAA0000489 DIODE [M]
D910 B0ADCJ000020 DIODE [M]
D971 MA2C16500E DIODE [M]
D1301 B0ACCK000005 DIODE [M]
D7650 MAZ80560ML DIODE [M]
88
SA-PM45E / SA-PM45EG / SA-PM45EE
