Ref.
No.
Part No. Part Name & Description Remarks
VARIABLE RESISTORS
VR900 EVEKE2F2524B VOLUME ENCODER [M]
SWITCHES
S900 EVQ21405RJ SW STOP [M]
S901 EVQ21405RJ SW CD PLAY [M]
S902 EVQ21405RJ SW TAPE/DPORT PLAY [M]
S903 EVQ21405RJ SW TUNER [M]
S904 EVQ21405RJ SW USB [M]
S905 EVQ21405RJ SW FF [M]
S906 EVQ21405RJ SW REW [M]
S907 EVQ21405RJ SW POWER [M]
S909 EVQ21405RJ SW BASS/TREBLE [M]
S910 EVQ21405RJ SW REC [M]
S911 EVQ21405RJ SW MPORT [M]
S912 EVQ21405RJ SW CD OPEN/CLOSE [M]
S971 K0J1BB000017 SW MODE [M]
S972 K0J1BB000021 SW HALF [M]
S975 K0J1BB000021 SW RECINH_F [M]
S1000 EVQ21405RJ SW TAPE EJECT [M]
S7201 RSH1A048-A SW RESET [M]
CONNECTORS
CN505B K1MN12A00031 12P WIRE HOLDER [M]
CN801 K1MN06A00013 FFC CONNECTOR [M]
CN802 K1MN22A00012 22P CONNECTOR [M]
CN803 RWJ0212140KQ 12P CONNECTOR [M]
CN804 K1MY19AA0124 19P FFC CONNECTOR [M]
CN807 K1MN22A00012 22P CONNECTOR [M]
CN900B RWJ1105205QX 5P WIRE (PANEL-TRAN) [M]
CN901A K1MY19AA0124 19P FFC CONNECTOR [M]
CN901B K1MY19AA0124 19P FFC CONNECTOR [M]
CN1303 K1MN19BA0005 19P CONNECTOR [M]
CN7001 K1MN16B00154 16P FFC CONNECTOR [M]
CN7002 K1MN22BA0005 22P CONNECTOR [M]
CP1301 K1MY05AA0043 5P CONNECTOR [M]
CP1902 K1KA09BA0153 9P CONNECTOR [M]
CS971 RJU071H09M1 9P CONNECTOR [M]
P901 K1MN22BA0005 22P CONNECTOR [M]
P903 K1FY104B0011 USB CONNECTOR [M]
COILS & TRANSFORMERS
L203 J0JBC0000019 CHIP INDUCTOR [M]
L204 G0C3R3JA0027 COIL [M]
L600 G0B371HA0005 LINE FILTER [M]
L803 J0JKB0000020 EMI BEAD CORE [M]
L804 G0C3R3JA0027 COIL [M]
L805 G0C3R3JA0027 COIL [M]
L806 G0C101JA0027 COIL [M]
L807 G0C101JA0027 COIL [M]
L900 G1C100K00019 CHIP COIL [M]
L901 G0C3R3JA0027 COIL [M]
L905 G0C101JA0027 COIL [M]
L1301 G2ZZ00000024 BIAS OCS COIL [M]
L1302 G0C470JA0052 RF CHOKE COIL [M]
LB320 J0JBC0000015 CHIP INDUCTOR [M]
LB321 J0JBC0000015 CHIP INDUCTOR [M]
LB840 J0JAC0000021 CHIP INDUCTOR [M]
LB841 J0JAC0000021 CHIP INDUCTOR [M]
LB843 J0JAC0000021 CHIP INDUCTOR [M]
LB845 J0JAC0000021 CHIP INDUCTOR [M]
LB846 J0JAC0000021 CHIP INDUCTOR [M]
LB848 J0JAC0000021 CHIP INDUCTOR [M]
LB850 J0JHC0000045 CHIP INDUCTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
LB852 J0JHC0000045 CHIP INDUCTOR [M]
LB930 J0JHC0000045 CHIP INDUCTOR [M]
LB932 J0JAC0000021 CHIP INDUCTOR [M]
LB933 J0JAC0000021 CHIP INDUCTOR [M]
LB934 J0JAC0000021 CHIP INDUCTOR [M]
LB935 J0JAC0000021 CHIP INDUCTOR [M]
LB936 J0JAC0000021 CHIP INDUCTOR [M]
LB938 J0JAC0000021 CHIP INDUCTOR [M]
LB951 J0JHC0000045 CHIP INDUCTOR [M]
LB952 J0JHC0000045 CHIP INDUCTOR [M]
LB7262 D0GBR00JA008 CHIP JUMPER [M]
LB7263 D0GBR00JA008 CHIP JUMPER [M]
LB7264 D0GBR00JA008 CHIP JUMPER [M]
T600 G4CYAYY00137 SUB TRANSFORMER [M]
T601 G4CYAYY00139 TRANSFORMER [M]
COMPONENT COMBINATION
Z401 ENG07823QF TUNER PACK [M]
Z600 ERZV10V511CS ZENER [M]
Z901 B3RAD0000143 REMOTE SENSOR [M]
RELAY
RL600 K6B1AEA00015 POWER RELAY [M]
OSCILLATORS
X320 H0H433400002 CRYSTAL OSCILLATOR [M]
X801 H4Z8004AA001 CERAMIC RESONATOR [M]
X802 H0A327200100 CRYSTAL OSCILLATOR [M]
X900 H0D120500009 CRYSTAL OSCILLATOR [M]
X7201 H2B169500005 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL900 A2BB00000166 FL DISPLAY [M]
FUSE / FUSE CLIPS
F1 EYF52BCY FUSE CLIP [M]
F1 K5D631BLA012 FUSE [M]
F2 EYF52BCY FUSE CLIP [M]
FUSE PROTECTORS
FP352 K5G502A00039 FUSE PROTECTOR [M]
FP601 K5G502A00039 FUSE PROTECTOR [M]
FP950 K5G102AA0002 FUSE PROTECTOR [M]
JACKS
JK303 K2HC1YYA0003 JK MUSIC PORT [M]
JK501 K4BC04B00123 JK RED/BLACK SPEAKER [M]
JK600 K2AA2B000015 JK AC INLET [M]
JK900 K2HC103A0024 JK HP [M]
CHIP JUMPERS
W137 ERJ8GEY0R00V CHIP JUMPER [M]
W140 ERJ8GEY0R00V CHIP JUMPER [M]
W183 ERJ8GEY0R00V CHIP JUMPER [M]
W233 ERJ8GEY0R00V CHIP JUMPER [M]
W500 ERJ6GEY0R00V CHIP JUMPER [M]
W503 ERJ3GEY0R00V CHIP JUMPER [M]
W504 ERJ6GEY0R00V CHIP JUMPER [M]
W505 ERJ3GEY0R00V CHIP JUMPER [M]
W506 ERJ6GEY0R00V CHIP JUMPER [M]
W507 ERJ3GEY0R00V CHIP JUMPER [M]
W521 ERJ6GEY0R00V CHIP JUMPER [M]
W523 ERJ6GEY0R00V CHIP JUMPER [M]
W541 ERJ6GEY0R00V CHIP JUMPER [M]
89
SA-PM45E / SA-PM45EG / SA-PM45EE
