Pin No. Mark I/O Function
78 PHOTO I Deck Photo SW Input (L:SW
On)
79 MOTOR_H O Deck Motor Control Output
(H:On)
80 TAPE_EJECT I Tape Eject SW Input (L:SW On)
81 PL_H O Deck Plunger Control Output
(H:ON)
82 REC_H O Deck Rec Control Output
(Active High)
83 N.C. - No Connection
84 DMT O Deck Mute Output (H:Mute ON)
85 CD_
OPEN_SW
I CD Open SW (H:Open;
L:Close)
86 REST_SW I REST SW (L: inner)
87 DLINKDET1 - No Connection
88 DLINKDET2 - No Connection
89 VDD - Micom VDD +5V
90 ACK_IN - No Connection
91 VSS - Ground Connection
92 KEY1 I Key 1 Input
93 KEY2 I Key 2 Input
94 MK-IN1 I Mech Condition Input 1 (Mode
and Tps)
95 MK-IN2 I Mech Condition Input 2 (Mode
and Tps)
96 DCDET I DC Level Detection Input
97 REGION I Region Setting Input
98 N.C. - No Connection
99 N.C. - No Connection
100 VREF + - A/D Converter reference voltage
+3.3V
82
SA-PM45E / SA-PM45EG / SA-PM45EE
