Panasonic SA-PM45PC - Page 3

15.5. USB CIRCUIT 58
16 Printed Circuit Board Diagrams
59
16.1. CD SERVO P.C.B and USB P.C.B
59
16.2. MAIN P.C.B
60
16.3. PANEL P.C.B, HEADPHONE P.C.B and MUSIC PORT
P.C.B
61
16.4. TRANSFORMER P.C.B
62
17 Illustration of IC 痴, Transistors and Diodes
63
18 Terminal Function of IC's
64
18.1. IC7001 (MN6627954MA) IC SERVO
PROCESSOR/DIGITAL SIGNAL PROCESSOR/DIGITAL
FILTER D/A CONVERTER
64
18.2. IC7002 (BA5948FPE2) IC 4CH Drive
65
18.3. IC803 (MN101EF16ZXW) MICROPROCESSOR
65
19 Exploded Views
67
19.1. Cabinet Parts Location
67
19.2. CD Unit Parts Location
68
19.3. Packaging
69
20 Replacement Parts List
71
3
SA-PM45PC
