Notes:
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0162 19P FFC WIRE [M]
3 REEV0164 22P FFC WIRE [M]
4 REEV0165 22P VFFC (USB) [M]
5 REXX0230-2 2P MAIN-CR120 WIRE [M]
6 RGBV0016-S PANASONIC BADGE [M]
7 RGKV0159-K PHONE ORNAMENT [M]
8 RGKV0160-K USB ORNAMENT [M]
9 RGKV0161-S VOLUME RING [M]
10 RGLV0071-Q POWER LIGHTING TIP [M]
11 RGUV0168-K FUNCTION BUTTON [M]
12 RGUV0169-S POWER/REC BUTTON [M]
13 RGUV0170-S CD EJECT BUTTON [M]
14 RGUV0171-S STOP/AUX BUTTON [M]
16 RGWV0047-S VOLUME KNOB [M]
17 RHD26046-L SCREW [M]
18 RHD30007-K2J SCREW [M]
19 RHDV30005 SCREW [M]
20 RHGV0008 LEG CUSHION [M]
22 RKFV0064-S CD LID [M]
23 RKMV0072-K1 FRONT CABINET [M]
24 RKMV0073-K SIDE PANEL L [M]
25 RKMV0074-K SIDE PANEL R [M]
26 RKMV0076-K1 TOP CABINET [M]
27 RKSV0037F-K REAR CABINET [M]
28 RKWV0069B-R FL WINDOW [M]
31 RMBV0043 EARTH SPRING [M]
32 RMKV0063 BOTTOM CHASSIS [M]
34 RMNV0062 FL HOLDER [M]
35 RSCV0086-1 USB CASING (BOTTOM) [M]
36 RSCV0087B-1 USB CASING (TOP) [M]
37 RSCV0088 REAR SHIELD PLATE [M]
40 RXXV0050 HEAT SINK UNIT [M]
41 SHE187-4J POWER PCB SUPPORT [M]
42 XTB3+10JFJK SCREW [M]
43 XTB3+20JFJK SCREW [M]
44 XTB3+8FFJ SCREW [M]
45 XTB3+8JFJ SCREW [M]
Ref.
No.
Part No. Part Name & Description Remarks
TRAVERSE DECK
301 RAE0165Z-V TRAVERSE W/O PCB [M]
302 RDG0460A CAM GEAR [M]
303 RDG0461A DRIVE GEAR [M]
304 RGQ0254-K2 TRAY [M]
305 RHD30083-1 CAM. GEAR SCREW [M]
306 RHM0001 MAGNET [M]
307 RMB0603-1 FLOATING SPRING [M]
308 RFKNANS55P-K CLAMPER HOLDER ASS’Y [M]
309 RME0288-1 CENTERING SPRING [M]
310 RMG0510-K FLOATING RUBBER (A) [M]
311 RMG0511-K FLOATING RUBBER (B) [M]
312 RMK0422A MECHA CHASSIS [M]
313 RMR1223-K1 CLAMP PLATE [M]
314 RMR1242-X3 FIXTURE [M]
315 XTN2+6GFJ SCREW [M]
316 K0F111E00093 OPEN SWITCH [M]
PRINTED CIRCUIT BOARD
REPV0119F MAIN P.C.B / PANEL P.C.B /
HEADPHONE P.C.B / MUSIC PORT
P.C.B / TRANSFORMER P.C.B
[M]
(RTL)
REPV0101A USB P.C.B. [M]
(RTL)
REPV0111A CD SERVO P.C.B [M]
(RTL)
INTEGRATED CIRCUITS
IC101 C0DAZYY00006 IC CD 7.5V REGULATOR [M]
IC102 C0DAZYY00005 IC USB 5V REGULATOR [M]
IC300 AN17831A IC POWER AMPLIFIER [M]
IC700 C0ABBB000297 IC OP-AMP [M]
IC800 C1BB00000732 IC ASP [M]
IC801 C0CAABC00007 IC REGULATOR [M]
IC802 C0EBE0000455 IC RESET [M]
IC803 MN101EF16ZXW IC MICROPROCESSOR [M]
20 Replacement Parts List
·
Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthe rmore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
·
The parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
·
Warning: This product uses a laser diode. Refer to “Precaution of Laser Diode”.
·
Capacitor values are in microfarads (µF) unless specified otherwise, P= Pico-farads (pF), F= Farads.
·
Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
·
The marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
·
[M] Indicates in the Remarks columns indicates parts supplied by PAVCSG.
·
Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp: Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian Ur: Ukraine Pr: Portuguese
71
SA-PM45PC
