Ref.
No.
Part No. Part Name & Description Remarks
IC900 C0HBB0000057 IC FL DRIVER [M]
IC900 MNZSFB5KJM1 IC USB CONTROLLER [M]
IC951 C0DBZYE00002 IC VOLTAGE REGULATOR [M]
IC7001 MN6627954MA IC SERVO
PROCESSOR/DIGITALSIGNAL
PROCESSOR/DIGITALFILTER D/A
CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Q221 B1ABGC000001 TRANSISTOR [M]
Q222 B1ABGC000001 TRANSISTOR [M]
Q421 B1ABGC000001 TRANSISTOR [M]
Q422 B1ABGC000001 TRANSISTOR [M]
Q600 B1AACF000063 TRANSISTOR [M]
Q601 2SC3940ARA TRANSISTOR [M]
Q602 B1GACFJJ0018 TRANSISTOR [M]
Q603 2SB0621AHA TRANSISTOR [M]
Q750 B1GDCFGG0026 TRANSISTOR [M]
Q751 B1GBCFJJ0044 TRANSISTOR [M]
Q803 B1GBCFJJ0044 TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
DIODES
D500 B0EAKM000117 DIODE [M]
D502 B0EAKM000117 DIODE [M]
D503 B0EAKM000117 DIODE [M]
D504 B0EAKM000117 DIODE [M]
D505 B0EAKM000117 DIODE [M]
D506 B0EAKM000117 DIODE [M]
D507 B0EAKM000117 DIODE [M]
D508 B0EAKM000117 DIODE [M]
D600 B0ACEL000004 DIODE [M]
D602 B0EAKM000117 DIODE [M]
D603 B0EAKM000117 DIODE [M]
D604 B0EAKM000117 DIODE [M]
D605 B0EAKM000117 DIODE [M]
D606 B0EAKM000117 DIODE [M]
D607 B0BC6R700006 DIODE [M]
D608 B0ACEL000004 DIODE [M]
D609 B0EAKM000117 DIODE [M]
D610 B0BC02900004 DIODE [M]
D611 B0EAKM000117 DIODE [M]
D612 B0EAKM000117 DIODE [M]
D613 B0EAKM000117 DIODE [M]
D614 B0EAKM000117 DIODE [M]
D615 B0EAKM000117 DIODE [M]
D616 B0EAMM000038 DIODE [M]
D617 B0EAMM000038 DIODE [M]
D618 B0EAMM000038 DIODE [M]
D619 B0EAMM000038 DIODE [M]
D621 B0EAKM000117 DIODE [M]
D622 B0EAKM000117 DIODE [M]
D623 B0EAKM000117 DIODE [M]
D624 B0EAKM000117 DIODE [M]
D750 B0ACEL000004 DIODE [M]
D751 B0ACEL000004 DIODE [M]
D800 B0ACCE000003 DIODE [M]
D801 B0ACCE000003 DIODE [M]
D802 B0ACEL000004 DIODE [M]
D804 B0ACEL000004 DIODE [M]
D805 B0ACEL000004 DIODE [M]
D900 B0BC5R600003 DIODE [M]
D906 B3AAA0000489 DIODE [M]
D910 B0ADCJ000020 DIODE [M]
D7650 MAZ80560ML DIODE [M]
VARIABLE RESISTORS
VR900 EVEKE2F2524B VOLUME JOG [M]
SWITCHES
Ref.
No.
Part No. Part Name & Description Remarks
S900 EVQ21405RJ SW FM [M]
S901 EVQ21405RJ SW CD [M]
S902 EVQ21405RJ SW USB [M]
S903 EVQ21405RJ SW STOP [M]
S904 EVQ21405RJ SW MUSIC PORT [M]
S905 EVQ21405RJ SW FF [M]
S906 EVQ21405RJ SW REW [M]
S907 EVQ21405RJ SW POWER [M]
S909 EVQ21405RJ SW BASS/TREBLE [M]
S910 EVQ21405RJ SW PRESET EQ [M]
S911 EVQ21405RJ SW AM [M]
S912 EVQ21405RJ SW CD OPEN/CLOSE [M]
S7201 RSH1A048-A SW REST [M]
CONNECTORS
CN505B K1MN12A00031 12P WIRE HOLDER [M]
CN801 K1MN06A00013 6P FFC CONNECTOR [M]
CN802 K1MN22A00012 22P CONNECTOR [M]
CN803 RWJ0212140KQ 12P FLAT WIRE [M]
CN807 K1MN22A00012 22P CONNECTOR [M]
CN900B RWJ1105205QX 5P WIRE [M]
CN901A K1MY19AA0124 19P FFC CONNECTOR [M]
CN901B K1MY19AA0124 19P FFC CONNECTOR [M]
CN7001 K1MN16B00154 16P FFC CONNECTOR [M]
CN7002 K1MN22BA0005 22P CONNECTOR [M]
P901 K1MN22BA0005 22P CONNECTOR [M]
P903 K1FY104B0011 USB CONNECTOR [M]
COILS & TRANSFORMERS
L203 J0JBC0000019 CHIP INDUCTOR [M]
L204 G0C3R3JA0027 COIL [M]
L600 G0B371HA0005 LINE FILTER [M]
L803 J0JKB0000020 EMI BEAD CORE [M]
L804 G0C3R3JA0027 COIL [M]
L805 G0C3R3JA0027 COIL [M]
L900 G1C100K00019 CHIP COIL [M]
L901 G0C3R3JA0027 COIL [M]
L905 G0C101JA0027 COIL [M]
LB840 J0JAC0000021 CHIP INDUCTOR [M]
LB841 J0JAC0000021 CHIP INDUCTOR [M]
LB843 J0JAC0000021 CHIP INDUCTOR [M]
LB845 J0JAC0000021 CHIP INDUCTOR [M]
LB846 J0JAC0000021 CHIP INDUCTOR [M]
LB848 J0JAC0000021 CHIP INDUCTOR [M]
LB850 J0JHC0000045 CHIP INDUCTOR [M]
LB852 J0JHC0000045 CHIP INDUCTOR [M]
LB930 J0JHC0000045 CHIP INDUCTOR [M]
LB932 J0JAC0000021 CHIP INDUCTOR [M]
LB933 J0JAC0000021 CHIP INDUCTOR [M]
LB934 J0JAC0000021 CHIP INDUCTOR [M]
LB935 J0JAC0000021 CHIP INDUCTOR [M]
LB936 J0JAC0000021 CHIP INDUCTOR [M]
LB938 J0JAC0000021 CHIP INDUCTOR [M]
LB951 J0JHC0000045 CHIP INDUCTOR [M]
LB952 J0JHC0000045 CHIP INDUCTOR [M]
LB7262 D0GBR00JA008 CHIP JUMPER [M]
LB7263 D0GBR00JA008 CHIP JUMPER [M]
LB7264 D0GBR00JA008 CHIP JUMPER [M]
T600 G4C2AAD00004 SUB TRANSFORMER [M]
T601 G4CYAYY00153 TRANSFORMER [M]
COMPONENT COMBINATION
Z401 ENG06836QF TUNER PACK [M]
Z600 ERZVA5Z471 ZENER [M]
Z901 B3RAD0000143 REMOTE SENSOR [M]
