3.3 Power supply equipment
Observe the following to prevent burnout, destruction of parts and unstable
arc.
welding power source
YD-350FD2HGY
YD-500FD2HGY
Input power source
Three phase ,380V/415V AC,
50 / 60 Hz (common)
Capacity
Commercial power source
20 kVA or more
35 kVA or more
Engine generator
Two times rated input or more
Input protection
(Power distribution box)
Fuse breaker
40 A
63 A
Molded case circuit breaker
(or leakage breaker)
50 A
80 A
Cross-section area
Of cable
Input power cable
6 mm
2
or more
10 mm
2
or more
Output power cable
50 mm2or more
70 mm2or more
Ground cable
The same as input power cable or bigger
Protection level
IP23S
Insulation level
main transformer 155 ℃( inductor 200 ℃)
class of pollution
Grade 3
EMC classification
A Grade
*1. The listed capacities of fuses and breakers (or leakage protectors) are only for reference.
*2. When the machine is working at the places where are moist or on the iron plate or stand, please be sure to
install leakage protector.
Note:
please follow the regulations listed below to avoid any damage of parts, unstable arc and overheat or damage of
the machine.
● The fluctuation range of input: the allowable rated input voltage is 304V ~ 456V.
● When the generator is used, the rated input capacity should be two times of cutting power source or higher. The
generator should be equipped with compensating coils.
● The wiring of input side: please equip each cutting power source with one fuse switch or non-fuse breaker (or
leakage breaker) of which capacity complies with the rated one of the cutting power source.
● Please select the proper breaker (or leakage breaker) which is applicable to electric distribution, such as cutting,
electric motor or transformer.
