Panasonic YD-500FD2 - 2 Rated Specifications; 2.1 Specifications table

Rated Specifications
4
2 Rated Specifications
2.1 Specifications table
Item
Unit
Contents
YD-350FD2
YD-500FD2
Control method
-
digital IGBT control
Rated input·
Number of phases
-
3-phase AC 380/415 V
Input power frequency
Hz
50/60
Rated input capacity
kVA/kW
17.6/13.5
29.9/23.9
Output characteristics
-
CV( constant voltage characteristics )
Rated output current
A
DC 350
Pulse OFF：DC 500
Rated output voltage
V
31.5
39
Rated duty cycle
%
60
Rated output no-load
voltage
V
DC 80
Output current range
(※Note)
A
DC 40~430
DC 60~500
Output voltage range
(※Note)
V
16~35.5
17~39
Welding method
-
individual / unitary
Enclosure protection
class
-
IP23S
Insulation class
-
main transformer 155 ℃( inductor 200 ℃)
EMC classification
-
A Grade
Cooling method
-
forced air cooling
Applicable welding wire
type
-
Al Si / Al Mg
Applicable welding wire
diameter
mm
Al Si / Al Mg1.2/1.6
Memory
-
100 channels can be called, welding parameters
recordable
Sequence
-
welding / welding — crater / initial — welding — crater /
spot welding
Shielding gas
-
MIG Al welding Ar:99.99%
Gas check time
-
60s ( longest gas check time )
Pre-flow time
-
0 s–5.0 s continuous adjustment (0.1 s increment)
After-flow time
-
0 s–5.0 s continuous adjustment (0.1 s increment)
Spot welding time
-
0.3 s–10.0 s continuous adjustment (0.1 s increment)
Capacity of liquid
cooling system
L
9
Cooling mode of liquid
cooling system
Coolant circulation cooling / water pump forced circulation
Cooling capacity of
liquid cooling system
kW
1.5
（
Test at 1 L / min flow rate
）
Coolant flow
L/min
>1（Matching Panasonic products）
Maximum range of
coolant
m
20
Overall dimensions
mm
1200x570x1060 ( LXWXH )
Mass
kg
124
133
