Panasonic YD-500FD2 - Fd2 Parts Diagram

Parts list
40
12.2 FD2 parts diagram
The No. column and digital S/N are in accordance with the same on parts configuration diagram.
S/N
Symbol
Part Name
Part Number
Quantity
Remarks
1
MTr
Main Transformer
TSMTU228
1
YD-350FD2HGY
TSMTU224
YD-500FD2HGY
2
L1
FCH Unit
TSMLU223
1
3
L2
Inductor
TSMLU183
1
YD-350FD2HGY
TSMLU187
YD-500FD2HGY
4
L3
Ring Inductor
TSMLU184
1
YD-350FD2HGY
TSMLU188
YD-500FD2HGY
5
Q1～Q4
IGBT
2MBI100TA065
4
6
R302～R305
Cement Resistor
RX274H40W5R0JW
4
7
D1
Rectifier Bridge
MDS60(C)-16
1
YD-350FD2HGY
MDS100(D)-16
YD-500FD2HGY
8
C300,C301
Electrolytic Capacitor
ECG2WWP272VD106CA
2
9
LF3
Current Sharing Ring Assembly
TSML0089
1
10
R300,R301
Discharge Resistor
RJG274L7W223J
2
11
C4,C5
Anti-Magnetic Biasing Capacitor
MKPHR1.5UF750V AC
2
12
R4～R7
Secondary Power Resistor
RX274H40W5R0JW
4
13
D2,D3
Diode Module
FRS300BA70
2
YD-350FD2HGY
D2，D3，
D4，D5
YD-500FD2HGY
14
Thp1
Thermal Relay
★US-602KXTMQL-75
1
YD-350FD2HGY
★US-602KXTMQL-83
YD-500FD2HGY
15
FAN
Fan
200FZY6-S(FC)
2
16
FAN
Fan Protective Cover
WZ-TG22580
1
17
MS
AC Contactor
★PT323001LS
1
YD-350FD2HGY
★NDC1T-5011MS
YD-500FD2HGY
19
R14
Cement Resistor
SFW40A471
1
20
FU5
Fuse
★61NR080H
1
wire feeder fuse
Fuse Holder
FHS07F
1
22
Eye Bolt
R825M10
2
26
R1，R2
Cement Resistor
SFW40A201
2
27
earth stud
R9074.17M8X16
1
28
Knob
TSMH0062
2
29
SW1
Power Source Switch
LAY39-30X/K2X
1
31
CO1
16 core socket
WS28K16Z-1.6
1
32
Output Terminal
★TSMDZ95-BK
★TSMDZ95-BR
1
1
33
TR2
Control Transformer
TSMU0866-口口
1
34
TR1
Control Transformer
TSMU0865-口口
1
35
FU7, FU8
Fuse
★660GH80ULTC
2
