Panasonic YD-500FD2 - Page 44

Parts list
41
S/N
Symbol
Part Name
Part Number
Quantity
Remarks
36
LF1
Input Filtering Assembly
TSMW2271-口口
1
37
PC Board
Switch Power Source PC Board
TSMP6910-口口
1
38
Wire Feeding PC Board
TSMP6550-口口
1
39
Drive PC Board
TSMP5491C-口口
2
40
CPU PC Board
TSMPA336-口口
1
YD-350FD2HGY
TSMPA337-口口
1
YD-500FD2HGY
41
Interface PC Board
TSMP638 口口
1
42
Operation PC Board
TSMPA300-口口
1
43
CT
Current transformer
L03S400D15WM
1
48
Ignition arc board
TSMP604 口
1
51
Flow switch assembly
TSMY0252
1
52
PM
Pump
MTP600HPSP1
1
53
TR3
Control Transformer
TSMU1019-口口
1
54
Coolant Storage Tank
TSMK3891
1
55
Radiator
TSMY0211
1
56
Pump Control PC Board
TSMP7480-口口
1
Note：★ stands for safety parts.
