[Timecode Setup]
[Time code setup] offers the ability to start a show based on an incoming Artnet timecode
signal. The FB4 will execute the file once the offset time mark has been received. The file
that is executed needs to be prepared through Laser Show Designer QuickShow or BEYOND
its FB4 export Utility.
[TC Type] ATC
[File Index] The actual file that will be executed as soon as the offset has been reached.
[Offset Hrs] The hour mark the FB4 should respond on.
[Offset Min] The minute mark the FB4 should respond on.
[Offset Sec] The second the FB4 should respond on.
[Offset mS] The millisecond the FB4 should respond on.
[Test mode Setup]
Test mode setup lets you test and setup your laser without the need to connect additional
equipment. Once operation mode [test mode] has been enabled, the [test mode setup]
becomes available. Test frames need to be uploaded through Laser Show Designer
QuickShow or BEYOND its FB4 Export Utility.
[Enable laser] Enables laser output
[Test pattern] Determines which test frame will be displayed
[Brightness] Determines the maximum brightness used during display of the test
frames
[Master size] Determines the X and Y size of the projection output. *
*Changing this value also changes [master size] in menu [master settings]
