Fixture mode FB4 - 39 channel DMX
The 39-channel fixture mode is meant to be used as follow;
1. Place the FB4 in “Setup mode”. (Note that there is a two second delay before “setup
mode” will initialize). Now limit the area where the laser may project.
2. Place the FB4 in “playback mode”.
Do the actual show performance and have the ability to use shape generators.
During “Setup mode”, channels 14 till 39 will ignore DMX/Art-net changes.
During “playback mode”, channels 2 till 13 will ignore DMX/Art-net changes.
Channels
Value
Description
Width
1*
0-255 Fixture Modes
0-239 Blackout / Safe
240-240 Setup Mode
251-251 Playback mode
8 Bit
2
0-255 Max Intensity
Defines the max intensity that can be
used during playback mode
(Range 0 till 100)
8 Bit
3
0--255 Test frames
Allows enabling test frames during
setup mode
(1= test frame 1, 255 = test frame 255)
8 Bit
4,5
0-65535 Size X
Defines the maximum width that can be
used during playback mode
(Range -100 till 100%, 0 = 32768)
16 Bit
6,7
0-65535 Size Y
Defines the maximum height that can
be used during playback mode
(Range -100 till 100%, 0 = 32768)
16 Bit
8,9
0-65535 Position X
Defines the horizontal position that can
be used during playback mode
(Range -100 till 100%, 0 = 32768)
16 Bit
10,11
0-65535 Position Y
Defines the vertical position that can be
used during playback mode
(Range -100 till 100%, 0 = 32768)
16 Bit
12,13
0-65535 Rotation Z
Defines the rotation angle that can be
used during playback mode
(Range 0 till 360 degrees)
16 Bit
14
0-255 Pages
Page Index, 255 pages in total
1 = page 1, 255 = page 255
8 Bit
15
0-255 Cues
Cue Index, 255 Cues in total
(1 = cue 1, 255 = cue 255)
8 Bit
16**
0-255 Cue speed
Cue speed
(0 = Original, 1 – 255 = 1% till 255%)
8 Bit
17
0-255 Dimmer
Defines the maximum brightness
limited by setup mode
(Range 0 till 100%)
8 Bit
