FB4 SE manual Version 0.91 Beta
25
Axis (X and Y scanner) Outputs
Axis Output
Pin Signal name Voltage level
1 Y Positive + -5V to +5V
2 Y Negative - -5V to +5V
3 GND
4 GND
5 X Negative - -5V to +5V
6 X Positive + -5V to +5V
