Fixture mode FB3 - 16 channel DMX
Below the layout of the 16-channel fixture profile. The 16 and 32 channel fixture profile are
not available at the same time.
Channels
Value
Description
Width
1
0-255 DMX Modes
0-31 Blackout
33-95 Four channels
97-159 Eight channels
161-232 Twelve channels
225-255 Sixteen channels
8 Bit
2
0-255 Page index
(9 pages in total)
0-15 Page 1
17-31 Page 2
33-47 Page 3
49-63 Page 4
65-79 Page 5
81-95 Page 6
97-111 Page 7
113-127 Page 8
129-255 Page 9
8 Bit
3
0-255 Cue Index
(48 cues in total)
0-32 None active
33-35 Cue 1
37-39 Cue 2
.. - .. ..
221-223 Cue 48
225-255 Repeat
8 Bit
4**
0-255 Cue Speed
0-15 Full Speed
17-31 Pause
33-255 25 till 200%
8 Bit
5
0-255 Dimmer
0 till 100%
8 Bit
6
0-255 Zoom
0 till 100%
8 Bit
7
0-255 Size X
-100 till 100%
8 Bit
8
0-255 Size Y
-100 till 100%
8 Bit
9
0-255 Angle Z
0 till 360 degrees
8 Bit
10
0-255 Position X
0 = left, 128 = Center, 255 = Right
8 Bit
11
0-255 Position Y
0 = top, 128 = center, 255 = bottom
8 Bit
12
0-255 Visible points
Zero Points till 100% of points visible
8 Bit
13***
0-255 Scan Rare
0-31 Cue speed
33-223 6K till 29K
225-255 30K
8 Bit
14
0-255 Cue release
0-31 Default
33-95 Hold
97-159 Loop
161-223 Next
225-255 Stop
8 Bit
15
0-255 Color Scroll
0-31 Original cue color
33-223 Color Scroll
225-255 White
8 Bit
16
Reserved
Reserved
8 Bit
