FB4 SE manual Version 0.91 Beta
22
18,19
0-65535 Zoom
Allows to zoom the cue limited by
setup mode
(Range 0 till 100%)
16 Bit
20,21
0-65535 X Size
Defines the maximum width limited by
setup mode
(Range -100 till 100%, 0 = 32768)
16 Bit
22,23
0-65535 Y Size
Defines the maximum height limited by
setup mode
(Range -100 till 100%, 0 = 32768)
16 Bit
24,25
0-65535 Z Angle
Defines the rotation angle limited by
setup mode
(Range 0 till 359 degrees)
16 Bit
26,27
0-65535 Z Rotation
Continues rotation from -60 till 60 Rpm
(Range, 0 = Original, 1 till 32767 =
-100% till -1% rotation, 32768 = keep
angle but do not rotate, 32769 till 65535
= 1% till 100% rotation)
28,29
0-65535 X Position
Allows for changing the horizontal
position of the cue limited by setup
mode
(Range -100 till 100%, center = 32768)
16 Bit
30,31
0-65535 Y Position
Allows for changing the vertical
position of the cue limited by setup
mode
(Range -100 till 100%, center = 32768)
16 Bit
32***
0-255 Scan Rate
Defines the painting speed of the laser
beam.
(5k till original 30K)
8 Bit
33
0-255 Red
Intensity range from 0 till 100%
8 Bit
34
0-255 Green
Intensity range from 0 till 100%
8 Bit
35
0-255 Blue
Intensity range from 0 till 100%
8 Bit
36
0-255 Alpha
Allows you to shift between original
cue color or RGB control.
(Range, 0 = original, 1-255 = 0 till
100% alpha blending)
8 Bit
37
0-255 Points start
Allows you to remove points from the
start point of a cue
(Range from 100 till 0% visibility)
8 Bit
38
0-255 Points end
Allows you to remove points from the
end point of a cue
(Range from 1000 till 0% visibility)
8 Bit
39
0-255 Strobe
0 = Strobe disabled
1-255 = Strobe from 1 to 20 Hz
8 Bit
* Set Channel one at least 2 seconds on DMX value 240 to activate setup mode.
Channel 2 till 12 can only be modified when channel one is in setup mode
During setup the red light on the FB4 will blink.
During playback mode, the red light will burn continuously.
