41
3.2.5 Sensors
Sensor name
Type
Location
Empty Sensor
Optical Sensor
Bottom-right of the transport unit
Feed Sensor
Optical Sensor
Bottom-right of the transport unit
Exit Sensor
Optical Sensor
Top-left of the engine board
Print cartridge top cover switch
Mechanical Switch
Top-right of the engine board
