Pantum P1000 Series Service Manual

- -
54
（2）Release three screws ① on the left.
（3）Release three screws ① on the right and then disassemble fixing unit ②.
4.3.12 Disassemble transfer unit
（1）(See section 4.3.11) Remove five screws ① at corners and bottom of development unit, and
then remove the whole transfer unit.
①
①
②
