（2）Release the three screws ①, then remove the panel ②.
4.3.11 Disassemble fixing unit
（1）(See sections 4.3.7 and 4.3.8) Release four screws ① after removing right side-cover and
left side-cover separately, and then disassemble engine side-board ②.
Note: When disassembling engine side-panel, some gears will be removed with it; please
maintain those gears.
