Pantum P1000 Series Service Manual

- -
77
F5 Fixing unit troubles
F6 Laser scanning error
F7 Unable to supply paper
F8 Insufficient high-voltage output
F9 USB cannot be identified by PC
Trouble causes
Solution
Thermistor not connected.
Reconnect the connector.
Thermostat is burnt out.
Change fixing unit.
Halogen heating lamp error.
Change fixing unit.
Trouble causes
Solution
The wire is connected improperly or broken.
Connect the wire properly, or change it.
The connectors CN3 and CN4 error.
Replace the connectors CN3 and CN4.
LSU damaged
Replace LSU
Trouble causes
Solution
Separation pad or feed roller error.
1) Clean the surface of the separation pad or feed
roller.
2) Change the separation pad or feed roller.
Connecting wire on electromagnet breaks.
Make sure the connecting wire on electromagnet
is connected properly.
High-voltage power supply error.
Change the engine board.
Electromagnet error.
Change electromagnet.
Actuator no paper error.
Change actuator no paper.
Trouble causes
Solution
Wires are unconnected or bad contact or
damaged.
Ensure the wires are connected well.
High-voltage contacting point polluted.
Clear the electrode.
Engineer board error.
Replace engineer board.
Trouble causes
Solution
The power cord is not plugged in or poorly
connected or damaged.
Make sure the power cord is connected properly.
The USB cable poorly contacted or damaged.
Make sure the USB cable is connected properly .
Power supplied from engine board to data board
error.
Replace data board.
Reset signal supplied from engine board to data
board error.
Detect the data board to make it provide correct
reset signal.
Engine board damaged.
Change for a new engine board.
