3-6 Installing the Drive
650 Series AC Drive
P3
72mm
26mm
54mm
7mm
mm
15.5
±
1
0
3.5
±
0.5
0
mm
32
±
2
0
mm
mm 5.5
±
0.5
mm
25
±
0.5
mm
58
±
0.5
Template
Cut-out
21
1
P3
4
3
Optional Equipment
Fitting the Remote 6511 Keypad
You can remote-mount the drive-mounted Keypad using:
• the (optional) RS232 (P3) port located under
the terminal cover
• A standard P3 lead, Parker SSD Drives' Part
Number CM057375U300, which is used to
connect the Keypad to the drive.
Two self-tapping screws are provided with the
Keypad. Remove the protective film from the
gasket. An enclosure rating of IP54 is achieved
for the remote Keypad when correctly mounted.
Assembly Procedure
Cut-out Dimensions
The drawing below can be photocopied actual size (100%) and used as a template.
