Parker 650 Series - Rive; Component Identification

2-1 An Overview of the Drive
650 Series AC Drive
1AN OVERVIEW OF THE DRIVE
Component Identification
5
6
7
4
1
8
3
2
10
11
Figure 2-1 View of Component Parts (Frame 1 illustrated)
1
Main drive assembly
7
Control terminals
2
Keypad
8
Volt-free relay contacts
3
DIN clip/fixing bracket
9
Product rating label
4
Terminal cover
10
Motor thermistor terminals
5
Power terminals
11
RS232 port - P3 (optional)
6
Motor cable screen clamp
Frame 2 Frame 1Frame 3
9
