Peekel Instruments User manual PICAS V2.6.1
Page 16 of 59
2.2.2 Potentiometer connection
5V
1mA
1
2
3
4
5
6
screen gnd
Figure 13: Potentiometer connection
2.2.3 Connection of a resistor sensor like a PT100
5V
1mA
1
2
3
4
5
6
screen gnd
Figure 14: Resistor connection
This connection diagram is used with a PT100 sensor.
