3.5.3 System-menu: Actions
This menu enables the user to order a number of centralized ACTIONS, which then can be
performed by the system in one go.
DEVICE 1
SYSTEM
CHOOSE ACTION :
ACTION :
SOURCE CHAN :
CHANNEL 1 :
CHANNEL 2 :
CHANNEL 3 :
CHANNEL 4 :
CALIBRATION
<execute>
01
YES
YES
YES
YES
MENU
ACTIONS
Controls and Functions
Choose Action selectable (Calibration / Copy Params / Auto-
Balance / Disable BAL. / Use Balance)
Action <execute>
Source Chan. selectable (01...04)
Channel 1 selectable (Yes / No)
Channel 2 selectable (Yes / No)
Channel 3 selectable (Yes / No)
Channel 4 selectable (Yes / No)
Functional Description
In the first line you can select the required action, hence you can have the instrument
<execute> that action by selecting the second line and pressing ENTER.
With Source Chan. you can select any one of 4 channels from which to copy parameters
Channel 1 ... Channel 4 can be set to YES or NO to instruct if such channel is taking part in
the centralized ACTION.
ACTION Description
Calibration When this command is given, the bridge supply will be calibrated with the
use of the sense lines.
Copy Params Copies the parameter from the source channel to the selected channel.
Auto Balance Performs an auto balance action to all selected channels.
Disable Bal Switches OFF the use of the balance function for the selected channels.
Use Balance Switches ON the use of the balance function for the selected channels.
