3.5.6 System-menu: Datalog
This menu is only available on devices where the datalog option is enabled. It allows the
user to perform a measurement and store measurement data in the internal memory of the
device. The memory will retain the data for 48 hours after switching the device off or
unplugging it from its power source. The data can be retrieved from the device at a later
time using a PC and the Signasoft 6000 software.
The differences in this function between the PB6000 and PB6100 controller are mentioned
in the text.
DEVICE 1
SYSTEM
INACTIVE
Off
<execute>
10 msec.
002
002
000
MENU
DATALOG
0.0%
Controls and Functions
Datalogging selectable (Inactive / Cyclic Log / Log & Fill RAM)
Logfilter selectable (Off / Dig.Input 1 / Dig. Input 2 / Trip Ch. 1 / ...)
Clear Buffer <execute>
for the PB6000 controller
Factor selectable (10 msec. / 1 sec)
Channel 1 editable (000 … 250)
Channel 2 editable (000 … 250)
Channel 3 editable (000 … 250)
Channel 4 editable (000 … 250)
for the PB6100 controller
Factor selectable (100usec / 1 sec
Channel 1 editable interval time, see text
Channel 2 editable interval time, see text
Channel 3 editable interval time, see text
Channel 4 editable interval time, see text
Functional Description
To store a measurement in RAM, the buffer must be empty. The device can not store
several different measurements in RAM. Select the clear buffer function and press ENTER
to remove previous measurement data. Beware: once the buffer has been cleared, the
measurement data can not be recovered.
To configure a measurement, the measurement interval must be configured for all
channels. The interval for all channels can be selected in steps.
PB6000: the selectable steps are 10 msec or 1 second.
For each channel, a number can be entered. This number, multiplied by the factor,
indicates the measurement interval for the channel. When '000' is entered for a
channel, that channel will not be measured.
