3.7.3 CA4AI menu: Range
Controls and Functions
Range of selectable (Signal V/V / Sensor)
Range selectable see table below.
Unit provided by system
Functional Description
The selection of Range of selection will influence the presentation of the measured value in
physical units. When Sensor is selected, the displayed value will be in the units entered in
the Sensor menu.
The selection of the Range value depends on the type of measurement selected in the
General menu and are:
Voltage Current Resistor Temperature measurement
+- 10V ± 100 mA
4000 Ω
PT100
-200 - +590 °C
+- 5V ± 50 mA
2000 Ω
PT1000
-200 - +590 °C
+- 2V ± 10 mA
500 Ω
Type B
+250 - + 1820 °C
+- 0.5 V ± 5 mA
100 Ω
Type E
-200 - + 1000 °C
+- 0.1 V Typ eJ
-200 - + 1200 °C
+- 50 mV Type K
-200 - + 1370 °C
+- 20 mV Type N
-200 - + 1300 °C
Type R
- 50 - + 1760 °C
Type S
- 50 - + 1760 °C
Type T
- 50 - + 390 °C
Device 1
Channel 3
Range of :
Range :
Unit :
Meas. value
10 V
V
Menu
Range
+00.006 V
