Peekel Instruments User manual PICAS V2.6.1
Page 52 of 59
3.7.2 CA4AI menu: Sensor
Controls and Functions
Physic.Unit selectable (N, Nm, N/mm
2
, Pa, ppm, psi, t, V,
V/V,%, bar,
o
C / g, g/mm
2
, G, Hz, inch, K,
lbs, m, m/m, m/s or m/s
2
)
Sensor-max adjustable (-10,000 . . . >>> . . . +10.000 with
selectable suffix (pico /... / Tera)
Sensor-min adjustable (-10,000 . . . >>> . . . +10.000 with
selectable suffix (pico /... / Tera)
Signal-max adjustable (-10,000 . . . >>> . . . +10.000 with
selectable suffix (pico /... / Tera)
Signal-min adjustable (-10,000 . . . >>> . . . +10.000 with
selectable suffix (pico /... / Tera)
Functional Description
When the range information of a sensor is known, this information can be entered in this
menu. At the fields Sensor max and Sensor min the physical limits of the sensor are
entered. At the field Signal max and Signal min the electrical signal values belonging to
the mentioned physical limits are entered.
PICAS will now calculate the correct physical value from each measured signal value.
