+ 04.738 V
+ 08.734 V
+ 06.432 V
+ 09.089 V
At the right side of the display the low and high peak values of each channel are displayed.
Those values are updated whenever the peak values changes. On the bottom of the display
2 commands are present. As shown above, none of these commands are selected. With
the left and right cursor keys a command can be selected. A selected command is
displayed between brackets, like <Reset>. The selected command can be given with the
enter Button.
When no command is selected, the enter button has the same functionality as by the
actual values display.
When the <Runn> is displayed, it means that the peak holding function is running. Pressing
the enter button when the <runn> command is selected, will stop the peak holding option.
The last peak values remain on the display, but will not be updated anymore. The <Runn>
text will be changed in <Hold>.
When the peak holding option is running, this function will be activated all the time, even
when the peak holding display is not on the screen.
The Hold/Runn and Reset commands can also be given in Set Meas.menu.
When a channel or system menu is displayed, and the measure button is pressed, the
setting in Set Meas. menu will determine, whether the actual value or the peak value
display is shown.
When the <Reset> command is given, the low peak values will be set at “++.+++”, and the
high peak values will be set at “--.---“.
If the Peak option is not running, and the reset command is given, the following display will
be presented:
+ 04.738 V
+ 08.734 V
+ 06.432 V
+ 09.089 V
When the peak holding option is on, every 10 milli seconds, 1 channel is measured. This
value is used for the peak holding determination. In this way every channel is converted
every 40 milli seconds.
When this display is presented, and the measure button is pressed again, the Sum-diff
value display will be presented.
