DEVICE ADDR :
CARRIER FREQ :
CF MASTER :
SERIAL NUMBR:
FIRMWARE :
CONTRAST[%] :
ENGLISH
001
5000 Hz
YES
00009918
FW-991012
57
MENU
GENERAL
Controls and Functions
Language selectable (English / Deutsch / Nederlands)
Device Address selectable (1 . . .>>>. . . 99)
Carrier frequency provided by system
CF Master selectable (Yes / No)
Serial number provided by system
Firmware (version no.) provided by system
Contrast selectable
Functional Description
Language: can be toggled here between English, German (Deutsch) and Dutch
(Nederlands). If you want to start-up always with the same language, you must specifically
save the system-settings from within the system -menu 3: “memory”.
Device Address: can be selected from 1 to 99 and is to be used when more than one
PICAS are connected to the bus.
Carrier frequency: this is automatically displayed and cannot be altered
CF-master: should always be set to yes if the device is operated separately. If more than
one PICAS is connected to the bus, only one is to be called the “master” and the other(s),
being “slaves”, should be set to no
When more PICAS systems are connected to each other through the RS485 bus, all the
PICAS systems should be master, or just 1 PICAS is master and all the other systems are
slave. If more then 1 PICAS is “master”, the synchronization frequency on the RS485 will
be the sum of the frequencies send by each PICAS. This signal will be out of specification
to be used for synchronizing the PICAS units. In this case the slave PICAS will not operate
within specifications.
Serial number: this is automatically displayed and cannot be altered
Firmware (version no.): this is the automatically displayed version-number of the firmware
installed and cannot be altered
Contrast: this is the contrast setting of the display. A higher number will darken the display.
