3.4 Measuring Display
To display the measurement values, PICAS has 4 display layouts:
Actual the actual value of the selected channel will be presented on the
PICAS display in a large font.
Peak values the low and high peak values of each channel will be presented on the
display.
Sum & Diff the sum and difference value of channel 1&2 and channel 3&4 will be
presented on the display
Bar graph for each channel a ‘bar graph’ is presented on the display. The actual
value is presented as a level in the bar graph. The actual values are
also presented in numbers, if there is room on the display.
When more then 4 channels are present in the PICAS, scrolling through the list of channel
values can be done with the arrow up / down keys.
Pressing the measure button, the selected view will be presented on the display.
Pressing this button again, will select the next display layout.
3.4.1 Actual value display
When the measure button is pressed, the following display will be presented:
DEVICE 1
+04.738
CHANNEL 1 V
+ 04.738 V
+ 01.546 V
+ 06.432 V
+ 09.089 V
Pressing the enter button, will change the unit of the presentation of the values in Signal
V/V, which presents the value of the input signal, Output V, which presents the output
voltage of the amplifier and Physic. Unit, which present the physical unit of the measured
signal. This selection can also be made in the presentation line on System menu 5.
When a measured value reaches the level of trip setting in channel menu, this trip status
will be presented on the display as follows:
DEVICE 1
+08.734
CHANNEL 2 TRIPPED V
+ 04.738 V
+ 08.734↑V
+ 06.432 V
+ 09.089 V
When this display is presented, and the measure button is pressed again, the peak value
display will be presented.
