BRUSH CUTTER EXCELION 2 DH
53_153238-A
2. To decrease a speed, push the selector (7) upwards.
5.4.3. “BOOST” MODE
The "Boost" mode allows you to instantly obtain the maximum rotational speed for the cutting head used (6600 rpm
for a blade, 6300 rpm for a strimmer wire).
Activating “Boost”
1. Simultaneously press the tool trigger and the safety
throttle fully for 1 second.
2. Push the selector (7) down for 0.5 second.
3. Make sure the screen flashes and displays the
"Boost" function.
The speed is then at its maximum for a period of 10
seconds.
Note
"Boost" cannot be activated when the tool is in
speed 4.
48
