pellenc EXCELION 2 DH - Angle Gear Lubrication

BRUSH CUTTER EXCELION 2 DH
53_153238-A
Always keep a distance of 3.7mm between the edge and
the relief on the blade.
6.7.5. ANGLE GEAR LUBRICATION
1. Remove the screw located on the CITY CUT using
the Torx 25 key (22) supplied with your tool.
2. Apply 4 grams of PELLENC grease (reference
35749) every 50 hours.
3. Replace the screw located on the CITY CUT using
the Torx 25 key (22) supplied with your tool.
71
