BRUSH CUTTER EXCELION 2 DH
53_153238-A
6.7. MAINTENANCE OF THE CITY CUT
6.7.1. DISMOUNTING/FITTING OF THE CITY CUT SAFETY GUARD
Dismounting
1. Dismount the CITY CUT (refer to the "dismount" part
of Section 4.4.6, « Fitting/dismounting the CITY CUT
on the tool »).
2. Using a T20 screwdriver, unscrew the 2 screws hol-
ding the CITY CUT safety guard in place.
3. Remove the 2 parts of the safety guard.
Fitting
1. Fit the 2 parts of the safety guard.
2. Using a T20 screwdriver, tighten the 2 screws hol-
ding the CITY CUT safety guard in place.
3. Refit the CITY CUT cutting head onto the tool (refer
to the "assembly" part of Section 4.4.6, « Fitting/dis-
mounting the CITY CUT on the tool »).
6.7.2. CHANGING THE CITY CUT BLADES
Dismounting
1. Unscrew the nut located under the cutting head with
a 13 mm wrench.
67
