Pentair EASYTOUCH PL4 Installation Guide

2
EASYTOUCH
®
PL4/PSL4 Control System Installation Guide
• IndoorControlPanel(P/N522465)–MonochromebacklitLCDcontrolpanel.Connectstothe
EasyTouch PL4/PSL4 Control System circuit board in the Power Center.
• WirelessController(P/N522464)–MonochromebacklitLCDcontrolpanel.Connectstothe
EasyTouch PL4/PSL4 Control System via a transceiver connected to the control system circuit
board in the Power Center.
• QuickTouch
®
II(P/N521245)andQT4(P/N520148)WirelessRemote:Four-function wireless
remote for pool and spa functions of your choice. This controller transmitter operates up to 150
feet range from the Power Center.
• iS4Spa-SideController(P/N520094):4-function (iS4) Spa-Side remote controller for pool
and spa functions of your choice. The controllers can operate up to 150 feet range from the
Power Center.
EasyTouch
®
PL4/PSl4 Control System Optional Accessories
Choose one or more of the following optional accessories to control pool and spa operations.
• iPhone
™
/iPad
®
TouchInterface(P/N520500) – Includes Protocol Interface Adapter that
connects to existing Desktop or Laptop PC. This allows control of EasyTouch PL4/PSL4
Control System via PC (requires PC with an Ethernet connection, and Windows
®
XP/Win7/Win8
operating system).
• iTC35Kit(P/N520502)– Includes in-wall color touch screen with Ethernet (RJ45) connection
and Protocol Interface Adapter and wireless router. The in-wall Touch screen is custom
conguredforEasyTouchPL4/PSL4andEasyTouchPL4/PSL4systems.RequiresanEthernet
cable to router.
iPhone
™
(for use with ScreenLogic2
™
)
QuickTouch
®
II Wireless Remote
(P/N 521245) Optional
Wireless Controller (3 AUX circuits)
(P/N 522464) Optional
Pantone Colors:
429 Buttons
431 Background
Indoor Control Panel (3 AUX circuits)
(P/N 522465) Optional
iS4 Spa-Side Remote
(P/N521885)Optional
