Pentair EASYTOUCH PL4 Installation Guide

6
EASYTOUCH
®
PL4/PSL4 Control System Installation Guide
MountingtheEasyTouch
®
PL4/PSL4 Control System Power
Center
MounttheEasyTouchPL4/PSL4ControlSystemPowerCenterenclosureonaatverticalsurface,
suchasawallorpostateyelevel,atleast5ft.(1.5m),(Canada3m(9.75ft))fromthepool,spaor
hot tub.
To mount the Power Center:
1. Positiontheenclosureagainstaverticalatsurface.Ifwallanchorsarebeingused,
supporttheenclosureinposition(horizontallylevelandsquare)againstthesurfaceand
mark the bracket hole pattern on the wall.
2. Secure the enclosure with three (3) screws in the top and lower mounting bracket holes. If
using wall anchors, drill and set the anchors and secure the enclosure with screws.
EasyTouch PL4/PSL4 Control System Power Center (front view)
(Front door and high voltage panel removed)
Lower mounting bracket screw holes
Top mounting bracket screw holes
