Recommended Hydraulic Schematic for Shared Equipment System
Plumbthesolarfeedandreturnlinesbetweenthelterandtheheater.Installathree-portvalve
at the feed line. Use a solar valve (model SOL-2T), to allow automatic draining of the panels.
A solar booster pump should be used when the distance to the panels exceed 200 ft., or the
panels are elevated higher than 25 ft.
Glazedsolarpanelsrequireadrainvalve(modelHW-5B)toallowdrainingofthepanels.This
prevents damage from overheating water. Install a drain valve at the solar feed line and connect
tothepoolllline.
SCGsystemsonly: IntelliChlor
®
Salt Chlorine Generator (SCG) cell with
checkvalveattheheateroutput.RefertoIntelliChlorSCGUser’sGuide(P/N520589)for
plumbing requirements.
EquipmentLocation
All equipment, with the exception of the spa-side remote, must be located at least 10 ft. from the
water’sedge.
9
10
11
INTELLICHLOR
PL4/PSL4 Indoor
Control Panel
PL4/PSL4 Wireless
Controller
Pantone Colors:
429 Buttons
431 Background
PL4/PSL4
Power Center
Control Panel
PL4/PSL4 Wireless
Transceiver
