Installer Manual Fleck 3150 - NXT - Spare parts and options
Ref. MKT-IM-010 / B - 28.05.2018 105 / 122
11.6.5. Threaded 4", tank 21" to 36", side mounted valve, top distribution system,
straight 63
mm, external glue connection
4 ATD-H60-00 Hub 1 1
5 AB-A6F-20 Hub adaptor 1 1
6 A-2106-48 Adaptor 1 1
7 A-2693-C Elbow 1 1
Item Part number Description
Assembly
quantity
Min. order
quantity
1 A-27UN-63 Top distribution system assy, slots 0.2 mm 1 1
- A-27UN-65 Top distribution system assy, slots 0.5 mm 1 1
2 A-8200-63 Union nut 1 1
3 A-8250-63 Collar 1 1
4 A-2694-17 O-ring 1 1
5 A-2752-32 Adapter 1 1
6 A-2740 Diffuser, slots 0.2 mm 1 1
- A-2746 Diffuser, slots 0.5 mm 1 1
Item Part number Description
Assembly
quantity
Min. order
quantity
