Installer Manual Fleck 3150 - NXT - Spare parts and options
116 / 122 Ref. MKT-IM-010 / B - 28.05.2018
11.6.12. Hot water, flanged 6", tank 21" to 36", side mounted valve, top and bottom
distribution system, external flange 65
mm connection, slots 0.2 mm
Item Part number Description
Assembly
quantity
Min. order
quantity
1 A3-2721-F6 Bottom distribution system assy, tanks 21" - 24" 1 1
- A3-2730-F6 Bottom distribution system assy, tank 30" 1 1
- A3-2736-F6 Bottom distribution system assy, tank 36" 1 1
2 A3-TH02-175 Lateral 175 mm, tanks 21" - 24" 6 6
- A3-TH02-268 Lateral 268 mm, tank 30" 6 6
- A3-TH02-330 Lateral 330 mm, tank 36" 6 6
3 A3D-H60-00 Hubcap 1 1
4 ATD3-H60-00 Hub distributor 1 1
5 A-3100-04C Prolongation 2 2
6 A-3100-02C Adaptor 1 1
