Page #24 background imageLoading...
Page #24 background image
16
IntelliFloXF
and IntelliProXF
Variable Speed Pump Installation and User’s Guide
EXT CONTROL
MENU
Pump Menu: External Control
External Control
This function is for programming speeds that will run when the IntelliComm power center
controller sends it a command. For example, Terminal 3 and 4 in IntelliComm will correspond
to External Control Program #1. (5 and 6 to Ext Ctrl #2). Use the External Control feature to
program the IntelliComm power center.
To access the External Control menu:
1. Check that the green power LED is on.
2. Press the Menu button.
3. Use Up or Down arrow to scroll to “Ext. Ctrl.”.
5. Press Select. “Program 1” is displayed.
6. Press Select. “750 RPM’ is displayed.
7. Press Select The “RPM” number will highlight.
8. Press Up or Down arrow to change the RPM setting.
9. Press Enter to save the setting.
Note: To cancel any changes, press the Escape button to exit without saving.
10. Press Escape to return to set Program 2.
11. Use Up or Down arrow to scroll to “Program 2”.
12. Repeat Steps 5 through 9 to set Program 2, 3, and 4-12 Programmable Speeds.
Pump Menu: Features
FEATURES
MENU
Quick Clean
This feature can be used to ramp the pump up to a higher RPM for vacuuming, cleaning,
adding chemicals, after a storm for extra skimming capability.
Press the Quick Clean button (LED on) and then Start/Stop to start. When the Quick Clean
cycle is over, the pump will resume regular schedules and be in “Running Schedule” mode.
To access the Quick Clean menu:
1. Check that the green power LED is on.
2. Press Menu.
3. Use Up or Down arrows to scroll to “Features”, then press Select.
4. Press the Down arrow and press Select for “Quick Clean”.
7. Press Select to choose “Set Speed”.
8. Press Select to highlight the “RPM” fi rst (ones) column and change the speed.
9. Use Up or Down arrows to change the speed.
10. Press Enter to save the speed.
11. Press the Down arrow again, and press Select for “Time Duration”.
12. Press Select to change the time. The cursor will highlight the minutes column.
13. Use Up or Down arrows to change the time from 1 minute to 10 hours.
14. Press Enter to save the time.
15. Press Escape to exit the menu.
