17
IntelliFloXF
™
and IntelliProXF
™
Variable Speed Pump Installation and User’s Guide
Pump Menu: Features
FEATURES
MENU
Time Out
This feature can be used to allow newly glued pipe joints time to dry before circulation of the
pool water resumes. Time Out keeps the pump from running it’s programmed speeds.
Once Time Out is fi nished, the pump will be in “Running Schedule” mode, Start/Stop LED
will be lit and ready to turn on at the next scheduled run time.
To access the Time Out menu:
1. Check that the green power LED is on.
2. Press Menu.
3. Use Up or Down arrows to scroll to “Features”, then press Select.
5. Press Select to choose “Timeout”.
6. Then press Select again to choose “Timeout Duration”.
7. Press Select to change the time. The cursor will highlight the minutes column.
8. Press the Left arrow to move cursor to the hours column.
Time out can be set from 1
minute to 10 hours.
9. Press Enter to save the setting.
Note: To cancel any changes, press Escape to exit without saving.
10. Press Escape to exit the menu.
PRIMING
MENU
Pump Menu: Priming
The default setting for Priming is ENABLED. This setting allows
the pump to automatically detect if it is primed for startup.
The priming feature ramps the pump to 1800 RPM and pauses
for three (3) seconds. If there is suffi cient water fl ow in the pump
basket, the pump will go out of priming mode and run its
commanded speed.
If the fl ow is not suffi cient, the pump will ramp to the “Max Speed”
setting and remain for the priming delay time (default 20 seconds).
If there is suffi cient water fl ow in the pump basket at this time, it
will go out of priming mode and ramp to the commanded speed.
If there is still insuffi cient fl ow in the pump basket, the pump will try to prime at the
“Maximum Speed” for the amount of time set up in the “Maximum Priming Time” menu.
Continue onto the next page for Priming
Display during priming
12:15p
1800 RPM
T 00:01 460 WATTS
Priming
To Next Page
