Pentair IntelliFloXF User Manual

33
IntelliFloXF
™
and IntelliProXF
™
Variable Speed Pump Installation and User’s Guide
Item No. Description IntelliFloXF IntelliProXF
1 Wet End Assembly
400000 401000
2 Union Kit Without Tap
3 Power End Assembly w/ Drive 400605 401605
4 Lid/Locking Ring Assembly
400006 401006
5 XF Series Replacement Basket
6 Lid/Locking Ring O-Ring
7 Drain Plug
071131 357161
8 Drain Plug O-Ring
9 2.5" Union Nut
10 2.5" C-Clip Locking Ring
11 2.5" Union Adapter without Tap
12 2.5" Diamond Seal Kit - 2 pcs
13 Motor Base
400004z 401004z
14 Motor Support Insert - Black
15 Acorn Nut
16 Split Lock Washer
17 Flat Washer
18 Diffuser O-Ring
19 Diffuser Screw
20 Diffuser
21 Impeller Reverse Screw
21 Impeller Reverse Screw O-Ring
22 Seal Plate O-Ring
23 Impeller Assembly
24 Mechanical Seal Assembly
25 Seal Plate
400002 401002
26 Motor Kit
350105s 357294s
27 Drive Hardware and Gasket Kit
28 Variable Speed Drive Assy. Kit
353251 353252
29 Field Wiring Comp Kit w/ Gasket
350621 353310
30 Control Cover Assy. Kit
350601 350701
Not Shown Hardware and Orings Kit
Not Shown Riser Plate XF to Challenger
Not Shown Seal Plate Kit With Mech Seal
400031z 400032z
350336
353323
37400-0028s
410001
410002
411000
410006z
410020
35505-1440
192115
400015
See Hydraulic Parts Table
072184
U43-12SS
071413
400007z
357160
400030z
400012
37337-6080
33455-1047
351446
350612
Replacement Parts
26
25
23
22
21
20
19
18
13 15 16 17
6
5
4
7
8
11109
2
1
3
29
27
12
28
30
2424
14
