Pentair IntelliPool User Manual

16
alarm
calib
on
AA
AA
AA
AA
1
2 3 4
alarmcalib
on
The radio relay may be exposed to very high temperatures. Using high-quality alkaline batteries resistant to temperatures up to +70 °C
(for example DURACELL PROCELL) is necessary.
1 - Remove the pot by pulling on the tab
2 - Install the 4 AA batteries (supplied)
3 - Re-connect the battery support
4 - The red LED flashes. Replace the cover.
Radio relay
The radio relay assures the link between the technical room (Control Center) and the house (indoor display and internet relay). It must be placed
vertically (on a wall, post) and far away from any metallic objects (iron fence, zinc gutter) and must not be directly exposed to the sun to ensure
reliable measurement of the air temperature. Perform tests (read the radio signal strength on screen, move the CALIB switch at the back of the
indoor display to update information) before permanently affixing it. If there is a very large distance between the pool and the house, a supplementary
radio relay can be added (as an option).
“Refreshing” the display of data by positioning the switch on “CALIB” then changing it back to “ON” (at the
back of the display) makes it possible to see - after 10 seconds - the radio force signal on each positioning
test of the radio relay.
Place the radio relay:
- Directly in the ground (planter)
- Between two pots on a windowsill
- To a stake or wall, using its screwed support
- Using its support with two cable ties
or
