Pentair IntelliPool User Manual

34
1
2
3
5
A
A
B
A
B
3
4
4
B
5
A
B
1
2
POOL COVER
pH
EMPTY TANK
USB rmware update
Radio programming
DISINFECT.
EMPTY TANK
WATER T°
pH
ORP
CONDUCT
AIR T°
Adding an indoor display
This RADIO mode makes it possible to add a second indoor display to set up a second source for reading your pool information.
1 - Briefly press RESET (0.5 sec) on the original display “A” (this displays “radio”). Note: press on plus for 4 sec until the alarm beep triggers
reinitialisation of the values.
2 - Remove the battery hatch of the new display “B”.
3 - Remove the insulation film of the battery of the new display “B”.
4 - The new display “B” changes into radio programming mode.
5 - The new display “B” shows the same values as the original display. Replace the battery hatch. Note: If the original remote display alarm values
have been adapted, they must be manually re-modified in the new display to be identical.
Re-learning of the original indoor display
The elements which constitute a set are paired with a unique radio code which prevents any risk of interference with other IntelliPool units (in the
vicinity, several pools close together) as a factory setting.
1 - Remove the flexible blue cover of the PROBE UNIT
2 - Press "radio programming". > The yellow LED lights up, the UNIT PROBE then emits a radio learning code for 5 minutes. Note: the start-up of
the remote display activates the recognition/automatic programming of a radio code.
3 - Remove the battery hatch
4 - Remove the insulating film
5 - The indoor display changes to radio learning mode > the indoor display shows the values . > Replace the battery hatch
