SECTION 5: XE Series 4” Submersible Motors
XE Series Motors
5.4 4” Motor Specifications
Table 5-1: Single Phase Motor Specifications (115 and 230 Volt, 60 Hz, 3450 RPM)
Motor Type
Pentek
®
Part
Number
Full Load Service Factor
Amps (Y/B/R) Y Only Watts Amps (Y/B/R) Y Only Watts
PSC
2-Wire
P42B0010A2-01 7.9 1679 9.1 1990
P42B0015A2-01 9.2 2108 11.0 2520
P42B0005A1-01 7.9 910 9.8 1120
P42B0005A2-01 4.0 845 4.7 1050
P42B0007A2-01 5.0 1130 6.2 1400
P42B0010A2-01 6.7 1500 8.1 1800
P42B0015A2-01 9.0 2000 10.4 2350
P42B0005A1 7.4 845 9.5 1088
P42B0005A2 3.7 834 4.7 1073
P42B0007A2 5.0 1130 6.4 1459
CSIR
3-Wire
P43B0005A1-01 8.8/8.8/0 8.8 675 10.9/10.9/0 10.9 980
P43B0005A2-01 5.3/5.3/0 5.3 740 6.1/6.1/0 6.1 1050
P43B0007A2-01 6.6/6.6/0 6.6 970 7.8/7.8/0 7.8 1350
P43B0010A2-01 8.1/8.1/0 8.1 1215 9.4/9.4/0 9.4 1620
P43B0005A1 11.0/11.0/0 11.0 733 12.6/12.6/0 12.6 1021
P43B0005A2 5.5/5.5/0 5.5 745 6.3/6.3/0 6.3 1033
P43B0007A2 7.2/7.2/0 7.2 1014 8.3/8.3/0 8.3 1381
P43B0010A2 8.4/8.4/0 8.4 1267 9.7/9.7/0 9.7 1672
CSCR
3-Wire
P43B0005A2-01 4.2/4.1/1.8 4.2 7.15 4.8/4.3/1.8 4.8 960
P43B0007A2-01 4.8/4.4/2.5 4.8 940 6.0/4.9/2.3 6.0 1270
P43B0010A2-01 6.1/5.2/2.7 6.1 1165 7.3/5.8/2.6 7.3 1540
P43B0015A2-01 9.1/8.2/1.2 9.1 1660 10.9/9.4/1.1 10.9 2130
P43B0005A2 4.1/4.1/2.2 4.1 720 4.9/4.4/2.1 4.9 955
P43B0007A2 5.1/5.0/3.2 5.1 1000 6.3/5.6/3.1 6.3 1300
P43B0010A2 6.1/5.7/3.3 6.1 1205 7.2/6.3/3.3 7.2 1530
P43B0015A2 9.7/9.5/1.4 9.7 1693 11.1/11.0/1.3 11.1 2187
P43B0020A2 9.9/9.1/2.6 9.9 2170 12.2/11.7/2.6 12.2 2660
P43B0030A2 14.3/12.0/5.7 14.3 3170 16.5/13.9/5.6 16.5 3620
P43B0050A2 24/19.1/10.2 24.0 5300 27.0/22.0/10.0 27 6030
