SECTION 2: Nomenclature
2.1 Motors
Table 2-1: Motor Nomenclature
Nomenclature
P 43 B 0 0 1 0 A 2 -01
Brand
P = PENTEK
Motor Size
42 = 4 inch, 2-wire
43 = 4 inch, 3-wire
Motor Material
B = All stainless steel
S = CBM
Horsepower
0005 = 1/2 HP
0007 = 3/4 HP
0010 = 1 HP
0015 = 1-1/2 HP
0020 = 2 HP
0030 = 3 HP
0050 = 5 HP
0075 = 7-1/2 HP
0100 = 10 HP
Frequency
A = 60 Hz.
B = 50 Hz.
C = 50/60 Hz.
Voltage
1 = 115 V, 1 Ph.
2 = 230 V, 1 Ph.
3 = 230 V, 3 Ph.
4 = 460 V, 3 Ph.
5 = 575 V, 3 Ph.
8 = 200 V, 3 Ph
Revision Code
Sample:
P43B0010A2-01 is a PENTEK 4” Stainless Steel Motor
1 HP, 60 Hz., 230 V, 1 Ph., Rev. 1
