Pentair Pentek Series User Manual

44
SECTION 7: Hitachi
®
6” and Larger Submersible Motors
7.7 Overload Protection
NEMA SIZE
MAX HP OF
CONTACTOR DISCONNECT A
MAX TOTAL A
OF PPX PANEL
O/L CURRENT
RANGE
CATALOG
NUMBER
DIMENSIONS
H x W x D
WEIGHT
(LBS.)
1 7.5 30
13.5
6.5 – 13.5
PPX-1A-13-30R
34 x 21 x 7
85
27 13 – 27 PPX-1A-27-30R 34 x 21 x 7 85
2 10 60 50 25 – 50 PPX-2A-50-60R 34 x 21 x 7 90
3 25 100
70 35 – 70 PPX-3A-70-100R 47.5 x 25 x 9 195
100 65 – 135 PPX-3A-135-100R 47.5 x 25 x 9 195
4 40 200 135 65 – 135 PPX-4A-135-200R 47.5 x 25 x 9 195
208 VAC
Note: For HPs with multiple part numbers, use motor amperage to select a panel.
Note: For HPs with multiple part numbers, use motor amperage to select a panel.
NEMA SIZE
MAX HP OF
CONTACTOR DISCONNECT A
MAX TOTAL A
OF PPX PANEL
O/L CURRENT
RANGE
CATALOG
NUMBER
DIMENSIONS
H x W x D
WEIGHT
(LBS.)
1 7.5 30
13.5 6.5 – 13.5 PPX-1B-13-30R 34 x 21 x 7 85
27 13 – 27 PPX-1B-27-30R 34 x 21 x 7 85
2 15 60 50 25 – 50 PPX-2B-50-60R 34 x 21 x 7 90
3 30 100
70 35 – 70 PPX-3B-70-100R 47.5 x 25 x 9 195
100 65 – 135 PPX-3B-135-100R 47.5 x 25 x 9 195
230-240 VAC
Note: For HPs with multiple part numbers, use motor amperage to select a panel.
NEMA SIZE
MAX HP OF
CONTACTOR DISCONNECT A
MAX TOTAL A
OF PPX PANEL
O/L CURRENT
RANGE
CATALOG
NUMBER
DIMENSIONS
H x W x D
WEIGHT
(LBS.)
1 10 30
13.5 6.5 – 13.5 PPX-1C-13-30R 34 x 21 x 7 85
27
13 – 27
PPX-1C-27-30R
34 x 21 x 7
85
2 25 60 50 25 – 50 PPX-2C-50-60R 34 x 21 x 7 90
3 50 100
70 35 – 70 PPX-3C-70-100R 47.5 x 25 x 9 195
100 65 – 135 PPX-3C-135-200R 47.5 x 25 x 9 195
4 100 200 135 65 – 135 PPX-4C-135-200R 47.5 x 25 x 9 195
5 200 400 270 130 – 270 PPX-5C-270-400R 52 x 22 x 10 285
460-480 VAC
Note: For HPs with multiple part numbers, use motor amperage to select a panel.
NEMA SIZE
MAX HP OF
CONTACTOR DISCONNECT A
MAX TOTAL A
OF PPX PANEL
O/L CURRENT
RANGE
CATALOG
NUMBER
DIMENSIONS
H x W x D
WEIGHT
(LBS.)
1 10 30
13.5 6.5 – 13.5 PPX-1D-13-30R 34 x 21 x 7 85
27
13 – 27
PPX-1D-27-30R
34 x 21 x 7
85
2 25 60 50 25 – 50 PPX-2D-50-60R 34 x 21 x 7 90
3 50 100
70 35 – 70 PPX-3D-70-100R 47.5 x 25 x 9 195
100 65 – 135 PPX-3D-135-100R 47.5 x 25 x 9 195
4 100 200 135 65 – 135 PPX-4D-135-200R 47.5 x 25 x 9 195
5 200 400 270 130 – 270 PPX-5D-270-400R 52 x 22 x 10 285
575-600 VAC
Hitachi
®
is a registered trademark of Hitachi Industrial Equipment Systems Co., Ltd.
