Pentair Pentek Series User Manual

17
SECTION 5: XE Series 4” Submersible Motors
5.5 4” Motor Dimensions
Table 5-5: Single Phase Motor Dimensions (115 and 230 Volt, 60 Hz, 3450 RPM)
Motor Type
Pentek
®
Part
Number
HP kW
Length Weight
Inches mm Lb Kg
4-Inch
2-Wire
P42B0005A1-01
1/2 0.37 10.5 267 18.1 8.2
P42B0005A2-01
P42B0007A2-01 3/4 0.55 11.9 302 21.4 9.7
P42B0010A2-01 1 0.75 12.5 318 23.2 10.5
P42B0015A2-01 1-1/2 1.1 14.2 361 27.3 12.4
P42B0005A1
1/2 0.37 11.0 279 19.2 8.7
P42B0005A2
P42B0007A2 3/4 0.55 12.4 314 22.7 10.3
P42B0010A2 1 0.75 13.3 337 24.5 11.1
P42B0015A2 1-1/2 1.1 14.9 378 28.9 13.1
4-inch
3-Wire
P43B0005A1-01
1/2 0.37
9.6 244 17.9 8.1
P43B0005A2-01 9.2 234 16.7 7.6
P43B0007A2-01 3/4 0.55 10.3 262 19.8 9.0
P43B0010A2-01 1 0.75 11.2 284 22.0 10.0
P43B0005A1
1/2 0.37
10.0 253 18.9 8.6
P43B0005A2 9.7 246 18.1 8.2
P43B0007A2 3/4 0.55 10.8 275 21.4 9.7
P43B0010A2 1 0.75 11.7 297 23.1 10.5
P43B0005A2-01 1/2 0.37 9.2 234 16.7 7.6
P43B0007A2-01 3/4 0.55 10.3 262 19.8 9.0
P43B0010A2-01 1 0.75 11.2 284 22.0 10.0
P43B0015A2-01 1-1/2 1.1 12.8 325 26.0 11.8
P43B0005A2 1/2 0.37 9.7 246 18.1 8.2
P43B0007A2 3/4 0.55 10.8 275 21.4 9.7
P43B0010A2 1 0.75 11.7 297 23.1 10.5
P43B0015A2 1-1/2 1.1 13.6 345 27.4 12.4
P43B0020A2 2 1.5 15.1 383 31.0 14.1
P43B0030A2 3 2.2 18.3 466 40.0 18.1
P43B0050A2 5 3.7 27.7 703 70.0 31.8
XE Series Motors
