SECTION 5: XE Series 4” Submersible Motors
5.7 Cable Lengths
Ta ble 5-9: Cable Lengths, SINGLE PHASE 115 and 230 Volt, 60 Hz, 3450 RPM, 2- and 3-wire Motors, 60° and 75° C.
Service Entrance to Motor: Maximum Length in Feet
Motor
Type
Pentek
®
Part
Number
HP Volt
Wire Size, AWG
14 12 10 8 6 4 3 2 1 0 00
PSC
2-Wire
P42B0005A1-01
1/2
115 112 178 284 449 699 1114 1401 1769 2229 2814 3550
P42B0005A2-01
230
464 739 1178 1866 2903 4628 5818 7347 9256 11684
P42B0007A2-01 3/4 353 562 897 1420 2210 3523 4429 5594 7046 8895 11222
P42B0010A2-01 1 271 430 686 1087 1692 2697 3390 4281 5394 6808 8590
P42B0015A2-01 1-1/2 211 335 535 847 1318 2100 2640 3335 4201 5303 6690
P42B0005A1
1/2
115 115 183 293 463 721 1150 1445 1825 2299 2902 3662
P42B0005A2
230
466 742 1183 1874 2915 4648 5843 7379 9295 11733
P42B0007A2 3/4 342 545 869 1376 2141 3413 4291 5419 6826 8617 10871
P42B0010A2 1 241 383 611 968 1506 2400 3018 3811 4801 6060 7646
P42B0015A2 1-1/2 199 317 505 801 1246 1986 2496 3153 3972 5013 6325
CSIR
3-Wire
P43B0005A1-01
1/2
115 101 160 255 404 629 1002 1260 1591 2004 2530 3192
P43B0005A2-01
230
359 571 912 1444 2246 3581 4502 5685 7162 9040
P43B0007A2-01 3/4 281 447 713 1129 1757 2800 3521 4446 5601 7070 8920
P43B0010A2-01 1 233 371 592 937 1458 2324 2921 3689 4648 5867 7402
P43B0005A1
1/2
115 87 138 221 349 544 867 1090 1376 1734 2188 2761
P43B0005A2
230
348 553 883 1398 2175 3467 4359 5505 6935 8753
P43B0007A2 3/4 264 420 670 1061 1651 2632 3309 4178 5264 6644 8383
P43B0010A2 1 226 359 573 908 1413 2252 2831 3575 4504 5685 7173
CSCR
3-Wire
P43B0005A2-01 1/2 457 726 1158 1835 2855 4551 5721 7225 9102 11489
P43B0007A2-01 3/4 365 581 927 1468 2284 3641 4577 5780 7281 9191 11596
P43B0010A2-01 1 300 478 762 1206 1877 2992 3762 4751 5985 7554 9531
P43B0015A2-01 1-1/2 201 320 510 808 1257 2004 2519 3182 4008 5059 6383
P43B0005A2 1/2 447 711 1135 1797 2796 4458 5604 7078 8916 11254
P43B0007A2 3/4 348 553 883 1398 2175 3467 4359 5505 6935 8753 11044
P43B0010A2 1 304 484 772 1223 1903 3034 3814 4817 6068 7659 9663
P43B0015A2 1-1/2 197 314 501 793 1234 1968 2474 3124 3936 4968 6268
P43B0020A2 2 180 286 456 722 1123 1790 2251 2843 3581 4520 5703
P43B0030A2 3 133 211 337 534 830 1324 1664 2102 2648 3342 4217
P43B0050A2 5 206 326 507 809 1017 1284 1618
2042 2577
* Table data are generated per NEC standards.
