SECTION 5: XE Series 4” Submersible Motors
Table 5-8: THREE PHASE Motor Fuse Sizing (230, 460, 200 and 575 Volt, 60 Hz, 3450 RPM)
Pentek
®
Part Number
HP kW Volts
Fuse Sizing Based on NEC
Standard
Fuse
Dual Element Time Delay Fuse
Circuit
Breaker
P43B0005A8
1/2 0.37
200 10 6 10
P43B0005A3 230 6 6 6
P43B0005A4 460 3 3 3
P43B0007A8
3/4 0.55
200 15 10 10
P43B0007A3 230 6 6 6
P43B0007A4 460 3 6 3
P43B0010A8
1 0.75
200 15 10 10
P43B0010A3 230 10 6 10
P43B0010A4 460 6 3 6
P43B0015A8
1-1/2 1.1
200 20 10 15
P43B0015A3 230 15 10 15
P43B0015A4 460 10 6 6
P43B0015A5 575 6 3 6
P43B0020A8
2 1.5
200 25 15 20
P43B0020A3 230 15 15 20
P43B0020A4 460 15 6 10
P43B0020A5 575 10 6 10
P43B0030A8
3 2.2
200 35 20 30
P43B0030A3 230 25 15 25
P43B0030A4 460 15 10 15
P43B0030A5 575 10 10 10
P43B0050A8
5 3.7
200 60 35 50
P43B0050A3 230 45 30 40
P43B0050A4 460 25 15 20
P43B0050A5 575 20 15 20
P43B0075A8
7-1/2 5.6
200 80 50 70
P43B0075A3 230 70 45 60
P43B0075A4 460 40 25 35
P43B0075A5 575 25 20 25
P43B0100A4 10 7.5 460 45 25 35
