23
SECTION 5: XE Series 4” Submersible Motors
Ta ble 5-10: Cable Lengths, THREE PHASE 230, 460, 200 and 575 Volt, 60 Hz, 3450 RPM Motors, 60° and 75° C.
Service Entrance to Motor: Maximum Length in Feet
Pentek
®
Part
Number
HP Volt
Wire Size, AWG
14 12 10 8 6 4 3 2 1 0 00
P43B0005A8
1/2
200 657 1045 1667 2641 4109
P43B0005A3 230 756 1202 1917 3037 4725 7532 9469
P43B0005A4 460 2922 4648 7414
P43B0007A8
3/4
200 423 674 1074 1702 2648
P43B0007A3 230 562 894 1426 2258 3513 5601 7041 8892
P43B0007A4 460 2191 3486 5560 8806
P43B0010A8
1
200 346 551 879 1392 2166 3454 4342
P43B0010A3 230 466 742 1183 1874 2915 4648 5843 7379
P43B0010A4 460 1753 2789 4448 7045
P43B0015A8
1-1/2
200 265 421 672 1064 1655 2638 3317
P43B0015A3 230 359 571 912 1444 2246 3581 4502 5685 7162 9040
P43B0015A4 460 1370 2179 3475 5504
P43B0015A5 575 2283 3631 5792
P43B0020A8
2
200 217 344 549 870 1354 2158 2714 3427 4317 5449
P43B0020A3 230 288 459 732 1159 1803 2874 3613 4563 5748 7256 9155
P43B0020A4 460 1153 1835 2926 4635 7212
P43B0020A5 575 1336 2126 3390 5370
P43B0030A8
3
200 159 253 403 638 993 1583 1990 2513 3166 3996
P43B0030A3 230 217 345 551 872 1357 2163 2719 3434 4326 5460 6889
P43B0030A4 460 827 1315 2098 3323 5171
P43B0030A5 575 1660 2641 4212 6671
P43B0050A8
5
200 94 150 239 379 590 940 1182 1493 1881 2374 2995
P43B0050A3 230 125 199 318 503 783 1248 1569 1982 2496 3151 3976
P43B0050A4 460 516 820 1308 2072 3224 5140
P43B0050A5 575 721 1147 1829 2897 4507
P43B0075A8
7-1/2
200 64 101 161 255 397 633 796 1005 1266 1598 2017
P43B0075A3 230 211 334 519 827 1040 1314 1655 2089 2635
P43B0075A4 460 325 516 824 1305 2030 3236 4068 5138 6472
P43B0075A5 575 548 871 1390 2202 3426
P43B0100A4 10 460 255 405 647 1024 1593 2540 3193 4033 5080
* Table data are generated per NEC standards.
XE Series Motors
